Cloud Browser API from n8n

Webhooks let external systems trigger rtrvr workflows via HTTP POST and let rtrvr send completion/failure callbacks back to your infrastructure. Use this for Zapier, Make, n8n, backend jobs, and server-to-server pipelines.

Platform Compatibility

Platform	HTTP Timeout	Compatibility	Recommended Approach
n8n	100s (Cloud)	Excellent	Direct calls work for most tasks
Make.com	Up to 300s	Excellent	Set timeout to 120s+
Zapier	30s fixed	Use callbacks	Provide webhookUrl for async results

Inbound Webhooks (Zapier, Make, n8n → rtrvr)

Any service that can send an HTTP POST can trigger rtrvr.ai workflows. Use the MCP endpoint to control your logged-in browser, or the /agent endpoint for cloud browser execution.

For a fixed task, the Cloud dashboard's Triggers panel (Cloud → Triggers) mints a per-trigger URL (POST https://mcp.rtrvr.ai/v1/webhooks/trigger/{id}, Bearer API key) whose target is a saved tool, a past cloud run, or a prompt stored on the trigger — a prompt trigger runs that prompt on every POST and appends the body's optional input to it.

MCP Endpoint (Your Browser)

text

POST https://mcp.rtrvr.ai

Headers:
  Authorization: Bearer rtrvr_your_api_key
  Content-Type: application/json

Body:
{
  "tool": "planner" | "extract" | "act" | "crawl" | "replay_workflow" | ...,
  "params": { ... tool-specific parameters ... },
  "deviceId": "optional_device_id",
  "webhookUrl": "https://your-server.com/callback"  // optional: receive results
}

Agent Endpoint (Cloud Browser)

bash

POST https://api.rtrvr.ai/agent

Headers:
  Authorization: Bearer YOUR_API_KEY
  Content-Type: application/json

Body:
{
  "input": "Extract company info and contact details",
  "urls": ["https://example.com"],
  "webhookUrl": "https://your-server.com/callback",
  "response": { "verbosity": "final" }
}

n8n Integration

n8n Cloud has a 100-second timeout — comfortably above most rtrvr task durations. Use either endpoint depending on whether you need your logged-in browser or a cloud browser.

json

// n8n → MCP (your logged-in browser)
{
  "method": "POST",
  "url": "https://mcp.rtrvr.ai",
  "body": {
    "tool": "planner",
    "params": {
      "user_input": "{{ $json.task_description }}",
      "tab_urls": ["{{ $json.target_url }}"]
    },
    "webhookUrl": "{{ $node.Webhook.url }}"
  }
}

// n8n → /agent (cloud browser)
{
  "method": "POST",
  "url": "https://api.rtrvr.ai/agent",
  "sendHeaders": true,
  "headerParameters": {
    "parameters": [
      { "name": "Authorization", "value": "Bearer {{ $credentials.rtrvrApiKey }}" },
      { "name": "Content-Type", "value": "application/json" }
    ]
  },
  "sendBody": true,
  "bodyParameters": {
    "parameters": [
      { "name": "input", "value": "={{ $json.taskDescription }}" },
      { "name": "urls", "value": "={{ [$json.targetUrl] }}" }
    ]
  }
}

Make (Integromat) Integration

01
Add an "HTTP > Make a request" module
02
URL: https://mcp.rtrvr.ai | Method: POST
03
Headers: Authorization (Bearer token), Content-Type (application/json)
04
Body type: Raw, Content type: JSON
05
Request content: Your tool + params JSON

Zapier Integration

Zapier has a fixed 30-second HTTP timeout. Use the webhook pattern: Zap 1 triggers rtrvr with a webhookUrl pointing to a Catch Hook in Zap 2, which receives and processes the results.

01
Add a "Webhooks by Zapier" action to your Zap
02
Select "POST" as the method
03
Set URL to: https://mcp.rtrvr.ai
04
Add headers: Authorization = Bearer rtrvr_your_api_key, Content-Type = application/json
05
Set Data to your JSON payload (tool + params)
06
Set webhookUrl to a Catch Hook URL in a second Zap

json

// Example: Extract data when a new row is added to Google Sheets
{
  "tool": "extract",
  "params": {
    "user_input": "Extract the company name, employee count, and funding info",
    "tab_urls": ["{{Google Sheets Row URL}}"]
  },
  "webhookUrl": "https://hooks.zapier.com/hooks/catch/123/abc/"
}

Available Tools

Tool	Use Case	Execution
agent	End-to-end task from one prompt; your signed-in Chrome when connected, else a cloud browser (target overrides)	Local or cloud browser
scrape	Read pages (text + accessibility tree); same routing as agent	Local or cloud browser
planner	Complex multi-step tasks from natural language	Local or cloud browser
extract	Structured data extraction with optional schema	Local or cloud browser
act	Page interactions (click, type, navigate)	Local or cloud browser
crawl	Multi-page crawling with extraction	Local or cloud browser
replay_workflow	Re-run a previous workflow by ID or URL	Local or cloud browser
get_browser_tabs	List open tabs	Local browser only
user_<toolName>	Run one of your saved tools (subroutines, custom JavaScript tools) with its parameters; your signed-in Chrome when connected, else a cloud browser	Local or cloud browser

Saved tools no longer need your Chrome open. A user_<toolName> call (REST tool, or the MCP tool of the same name) runs on your extension when a device is connected and falls back to a cloud browser otherwise; pass target: "cloud" to force the cloud browser or target: "device" to keep the old behaviour (a 503 when nothing is connected). Cloud runs open the tool's page in a browser signed in through Cookie Sync, bill browser time and inference like an agent run (creditsUsed is in the response), and answer 202 accepted with a trajectoryId when the tool is still running after ~25 seconds — add a webhookUrl to receive the result, or read it from Cloud executions. Cloud execution needs an API key with the cloud agent capability.

Outbound Webhooks (rtrvr → Your Server)

Include a webhookUrl in any API request to receive results when the workflow completes. rtrvr.ai will POST the full response to your endpoint.

Enabling Outbound Webhooks

bash

curl -X POST "https://mcp.rtrvr.ai" \
  -H "Authorization: Bearer rtrvr_xxx" \
  -H "Content-Type: application/json" \
  -d '{
    "tool": "planner",
    "params": {
      "user_input": "Find pricing for iPhone 16 Pro on Apple.com",
      "tab_urls": ["https://apple.com"]
    },
    "webhookUrl": "https://your-server.com/rtrvr-callback",
    "webhookSecret": "your_hmac_secret"
  }'

Webhook Payloads

Success Payload

json

{
  "event": "workflow.completed",
  "timestamp": "2025-01-15T12:00:00.000Z",
  "requestId": "req_abc123xyz",
  "success": true,
  "data": {
    "taskCompleted": true,
    "output": { ... },
    "extractedData": [ ... ],
    "creditsUsed": 5
  },
  "metadata": {
    "tool": "planner",
    "deviceId": "dj75mmaTWP0",
    "executionTime": 15234,
    "creditsRemaining": 9995
  },
  "originalRequest": {
    "tool": "planner",
    "params": { ... }
  }
}

Error Payload

json

{
  "event": "workflow.failed",
  "timestamp": "2025-01-15T12:00:00.000Z",
  "requestId": "req_abc123xyz",
  "success": false,
  "error": {
    "message": "Device offline: no available browser extensions",
    "code": "DEVICE_UNAVAILABLE",
    "details": { ... }
  },
  "metadata": { "tool": "planner", "executionTime": 1234 }
}

Verifying Webhook Signatures

If you provide a webhookSecret, rtrvr.ai signs the payload with HMAC-SHA256. Verify it to ensure authenticity:

typescript

// Express.js
import crypto from 'crypto';

app.post('/rtrvr-callback', express.raw({ type: 'application/json' }), (req, res) => {
  const signature = req.headers['x-rtrvr-signature'] as string;
  const timestamp = req.headers['x-rtrvr-timestamp'] as string;

  // Reject stale timestamps (> 5 minutes)
  if (Date.now() - parseInt(timestamp) > 300000) {
    return res.status(400).json({ error: 'Timestamp too old' });
  }

  const payload = timestamp + '.' + req.body.toString();
  const expected = crypto
    .createHmac('sha256', process.env.RTRVR_WEBHOOK_SECRET!)
    .update(payload)
    .digest('hex');

  if (!crypto.timingSafeEqual(Buffer.from(signature), Buffer.from(expected))) {
    return res.status(401).json({ error: 'Invalid signature' });
  }

  const data = JSON.parse(req.body.toString());
  // Process asynchronously — respond 200 immediately
  res.status(200).json({ received: true });
  processWebhook(data);
});

python

# Flask
import hmac, hashlib, time, os
from flask import Flask, request, jsonify

WEBHOOK_SECRET = os.environ['RTRVR_WEBHOOK_SECRET']

@app.route('/rtrvr-callback', methods=['POST'])
def handle_webhook():
    signature = request.headers.get('X-Rtrvr-Signature')
    timestamp = request.headers.get('X-Rtrvr-Timestamp')

    if abs(time.time() * 1000 - int(timestamp)) > 300000:
        return jsonify({'error': 'Timestamp too old'}), 400

    payload = f"{timestamp}.{request.data.decode()}"
    expected = hmac.new(WEBHOOK_SECRET.encode(), payload.encode(), hashlib.sha256).hexdigest()

    if not hmac.compare_digest(signature, expected):
        return jsonify({'error': 'Invalid signature'}), 401

    data = request.json
    return jsonify({'received': True})  # Process async

Retry Behavior

Failed deliveries are retried with exponential backoff:

01
Attempt 1: Immediate
02
Attempt 2: After 5 seconds
03
Attempt 3: After 30 seconds
04
Attempt 4: After 2 minutes
05
Attempt 5: After 10 minutes (final)

Common Patterns

Lead Enrichment Pipeline

New lead in CRM → rtrvr extracts company data → webhook returns enriched info → update CRM record.

json

// Trigger: New HubSpot contact
// Action: POST to https://api.rtrvr.ai/agent
{
  "input": "Visit this company website and extract: company size, industry, tech stack, and key contacts",
  "urls": ["{{contact.company_website}}"],
  "webhookUrl": "https://hooks.zapier.com/catch/123/enrich/",
  "response": { "verbosity": "final" }
}
// Webhook receives enriched data → Update CRM

Browser Trigger → Sheet Log (Zero Server)

The simplest pattern: monitor a site for notifications and log events to Google Sheets. No server, no API, no webhook endpoint needed.

01
Create a workflow that extracts data from the site and appends to a Google Sheet
02
Set up a Browser Trigger on that site with appropriate filters
03
Configure sheet output to "Append to same sheet on each run"
04
Every matching notification adds a row — building a running log automatically

Scheduled Price Monitoring

Cron schedule → rtrvr checks competitor prices → compare with previous data → alert if changed.

json

// Schedule: Daily at 9am via n8n Cron node
// Action: POST to https://api.rtrvr.ai/scrape
{
  "urls": [
    "https://competitor1.com/pricing",
    "https://competitor2.com/pricing"
  ]
}
// Compare extracted prices with yesterday's data
// If changed → Send Slack/email notification

Browser Trigger + Outbound Webhook (Hybrid)

text

Flow:
  1. Browser Trigger monitors slack.com for "deployment failed" notifications
  2. Trigger fires → workflow extracts error details from the Slack thread
  3. Workflow calls your server via rtrvr.ai API with webhookUrl set
  4. Server receives error details → creates a Jira ticket automatically

Result: Slack notification → browser extraction → server-side ticket creation
        No Slack API required — the browser does the heavy lifting

Authenticated Data Sync (MCP)

Your app triggers → rtrvr uses your logged-in browser via MCP → data synced to your database.

json

// Trigger: Webhook from your application
// Action: POST to https://mcp.rtrvr.ai
{
  "tool": "extract",
  "params": {
    "user_input": "Export my order history from the last 30 days",
    "tab_urls": ["https://vendor-portal.com/orders"]
  },
  "webhookUrl": "https://your-app.com/api/orders/sync"
}
// Your browser navigates using your login session
// Results sent to webhook → stored in database

Zapier → rtrvr → Zapier (Round-trip)

01
Zap 1: New Google Form submission → POST to mcp.rtrvr.ai (include webhookUrl pointing to Zap 2)
02
Zap 2: Catch Hook receives results → Add row to Google Sheets

Slack Command → rtrvr → Slack Message

typescript

app.post('/slack/commands', async (req, res) => {
  const { text, response_url } = req.body;
  res.status(200).json({ text: '🔄 Running extraction...' }); // Ack < 3s

  await fetch('https://mcp.rtrvr.ai', {
    method: 'POST',
    headers: { 'Authorization': 'Bearer rtrvr_xxx', 'Content-Type': 'application/json' },
    body: JSON.stringify({
      tool: 'extract',
      params: { user_input: text, tab_urls: [extractUrlFromText(text)] },
      webhookUrl: 'https://your-server.com/slack-callback',
      webhookMetadata: { response_url },
    }),
  });
});

app.post('/slack-callback', async (req, res) => {
  const { data, originalRequest } = req.body;
  const { response_url } = originalRequest.webhookMetadata;

  await fetch(response_url, {
    method: 'POST',
    headers: { 'Content-Type': 'application/json' },
    body: JSON.stringify({
      text: `✅ Extracted: ${JSON.stringify(data.extractedData, null, 2)}`,
    }),
  });
  res.status(200).json({ received: true });
});

Choosing the Right Approach

Approach	Trigger Signal	Best For	Availability
Browser Triggers	Push notification in a tab	Sites without APIs — social media, chat, SaaS dashboards	While Chrome is open
Schedules	Cron / interval timer	Periodic collection, monitoring, recurring reports	Chrome or 24/7 cloud
Inbound Webhooks	HTTP POST from external service	Zapier / Make / n8n, CI/CD, server-to-server	24/7 cloud

Best Practices

01
Verify signatures on every callback in production
02
Implement idempotency to handle retries safely
03
Use HTTPS-only endpoints
04
Pass webhookMetadata for correlation IDs and routing context

Platform

HTTP Timeout

Compatibility

Recommended Approach

n8n

100s (Cloud)

Excellent

Direct calls work for most tasks

Make.com

Up to 300s

Excellent

Set timeout to 120s+

Zapier

30s fixed

Use callbacks

Provide webhookUrl for async results

Tool

Use Case

Execution

agent

End-to-end task from one prompt; your signed-in Chrome when connected, else a cloud browser (target overrides)

Local or cloud browser

scrape

Read pages (text + accessibility tree); same routing as agent

Local or cloud browser

planner

Complex multi-step tasks from natural language

Local or cloud browser

extract

Structured data extraction with optional schema

Local or cloud browser

act

Page interactions (click, type, navigate)

Local or cloud browser

crawl

Multi-page crawling with extraction

Local or cloud browser

replay_workflow

Re-run a previous workflow by ID or URL

Local or cloud browser

get_browser_tabs

List open tabs

Local browser only

user_<toolName>

Run one of your saved tools (subroutines, custom JavaScript tools) with its parameters; your signed-in Chrome when connected, else a cloud browser

Local or cloud browser

Approach

Trigger Signal

Best For

Availability

Browser Triggers

Push notification in a tab

Sites without APIs — social media, chat, SaaS dashboards

While Chrome is open

Schedules

Cron / interval timer

Periodic collection, monitoring, recurring reports

Chrome or 24/7 cloud

Inbound Webhooks

HTTP POST from external service

Zapier / Make / n8n, CI/CD, server-to-server

24/7 cloud

MCP Endpoint (Your Browser)

Agent Endpoint (Cloud Browser)

n8n Integration

Make (Integromat) Integration

Zapier Integration

Available Tools

Enabling Outbound Webhooks

Success Payload

Error Payload

Lead Enrichment Pipeline

Browser Trigger → Sheet Log (Zero Server)

Scheduled Price Monitoring

Browser Trigger + Outbound Webhook (Hybrid)

Authenticated Data Sync (MCP)

Zapier → rtrvr → Zapier (Round-trip)

Slack Command → rtrvr → Slack Message

Run the example on a real site.

MCP Endpoint (Your Browser)

Agent Endpoint (Cloud Browser)

n8n Integration

Make (Integromat) Integration

Zapier Integration

Available Tools

Enabling Outbound Webhooks

Success Payload

Error Payload

Lead Enrichment Pipeline

Browser Trigger → Sheet Log (Zero Server)

Scheduled Price Monitoring

Browser Trigger + Outbound Webhook (Hybrid)

Authenticated Data Sync (MCP)

Zapier → rtrvr → Zapier (Round-trip)

Slack Command → rtrvr → Slack Message

Run the example on a real site.
